Premium Heavy Duty Shipping Container Double Doors with PU Foam Insulation, Galvanized Steel Construction, and Multi-Point Locking System
Premium Heavy Duty Shipping Container Double Doors with PU Foam Insulation, Galvanized Steel Construction, and Multi-Point Locking System
Not Your Standard Steel Double Door
These shipping container double personnel doors have been engineered purposely for the shipping container manufacturing and conversion industry. PU foam insulation, a fully welded, prebuilt frame, and sealed joints make for a stiff, rigid door set ready for easy installation when welding into a shipping container. An increased tolerance has been factored in to allow for movement in the shipping container when in transit or when positioned on an uneven surface.
Finish
Wet sprayed with a grey primer finish, the paint has been designed to take your final paint coat on-site. We recommend painting within 24 hours of installation.
Construction
Manufactured with 1mm galvanized steel door skins and 2mm galvanized steel frames.
Insulation
Insulated with polyurethane foam (also known as PU foam), the door leaf and frame are injected with PU foam for superior insulation values and improved strength and rigidity.
Internal Reinforcements
A full subframe, weld mesh, door closer reinforcing plate, and additional corner struts are welded inside the door for additional strength and integrity.
Locking System
The multi-point locking system is integrated into our container personnel doors. The locking system is protected with 2mm lock boxes and stainless steel tubes to protect the connecting rods. An adjustable latch keep is integrated to the strike plate and lock box, allowing for on-site adjustments. Two flush bolts also secure the passive leaf in place.
DDA Compliant Threshold
This door complies with the Disability Discrimination Act by having a level threshold with a maximum upstand of only 12mm with chamfered edges. The threshold is manufactured from stainless steel.
Technical Specifications
| Specification | Measurement |
|---|---|
| Steel Skin Thickness | 1mm |
| Steel Frame Thickness | 2mm |
FAQ
-
Q: Are these doors insulated?
A: Yes, the doors are insulated with polyurethane foam for superior insulation values. -
Q: What is the locking mechanism like?
A: The doors feature a multi-point locking system with 2mm lock boxes and stainless steel tubes for protection. -
Q: Is the door compliant with accessibility standards?
A: Yes, the door has a DDA compliant threshold with a maximum upstand of 12mm.
